| Performance of 1st cable layer | |||||
|
Line Pull
|
Line Speed (approx)
|
Current (amp)
|
|||
|
Lbs.
|
Kgs.
|
FPM
|
MPM
|
12V
|
24V
|
|
0
|
0
|
10
|
3.0
|
35
|
30
|
|
2000
|
900
|
8.8
|
2.7
|
85
|
60
|
|
4000
|
1810
|
7.3
|
2.2
|
130
|
110
|
|
6000
|
2710
|
6
|
1.8
|
200
|
160
|
|
8000
|
3620
|
5
|
1.5
|
260
|
240
|
|
9000
|
4086
|
4.3
|
1.3
|
300
|
280
|
| Line pull and cable capacity by layer | |||
|
Lbs.
|
Kgs.
|
Ft
|
M
|
|
1/9000
|
4086
|
15
|
5
|
|
2/7300
|
3318
|
38
|
11.5
|
|
3/6200
|
2818
|
64
|
19.5
|
|
4/5400
|
2454
|
95
|
29
|
|
5/4200
|
1900
|
100
|
30.5
|
Warning: To prevent serious injury: Do not use winches to move people:
Not intended for commercial use: Keep hand clear of
wire rope and fairlead opening during operation and when spooling
