| Performance of 1st cable layer | |||||
|
Line Pull
|
Line Speed (approx)
|
Current (amp)
|
|||
|
Lbs.
|
Kgs.
|
FPM
|
MPM
|
|
|
|
0
|
0
|
21.3
|
6.5
|
65
|
|
|
2000
|
907
|
11.5
|
3.5
|
126
|
|
|
4000
|
1814
|
9.4
|
2.85
|
175
|
|
|
6000
|
2722
|
7.9
|
2.4
|
230
|
|
|
8000
|
3620
|
6.5
|
2
|
280
|
|
|
10000
|
4532
|
5.7
|
1.75
|
355
|
|
|
12000
|
5440
|
4.4
|
1.35
|
400
|
|
| Line pull and cable capacity by layer | |||
|
Lbs.
|
Kgs.
|
Ft
|
M
|
|
1/12000
|
5440
|
16
|
5
|
|
2/9210
|
4170
|
42
|
12
|
|
3/8030
|
3640
|
72
|
21
|
|
4/6894
|
3125
|
94
|
28
|
Warning: To prevent serious injury: Do not use winches to move people:
Not intended for commercial use: Keep hand clear of wire rope and
fairlead opening during operation and when spooling
